| Part Number | TM080XPH01 |
| Mark | Tianma |
| Gréisst | 8.0 |
| Applikatioun | MP4 |
| Opléisung | 1280×768 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | No B/L |
| Interface | Mini LVDS |
| Panel Mark | TIANMA |
| Panel Modell | TM080XPH01 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 8.0 inch |
| Resolutioun | 1280(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 173.76×104.256 mm |
| skizzéieren | 181×112.8×3.05 mm |
| Uewerfläch | |
| Glas Déift | 0.50+0.50 mm |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 25/25 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | Mini LVDS, 40 pins |
| Input Volt | 3.3/12.5/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Applikatioun | MP4 |
