| Part Number | TV080WUM-AK1 |
| Mark | BOE |
| Gréisst | 8.0 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD , Assem |
| Hellegkeet | |
| CR | 850:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S3P |
| Interface | |
| Panel Mark | BOE |
| Panel Gréisst | 8.0" |
| Resolutioun | 1200(RGB)×1920, WUXGA, 283PPI |
| Affichage Beräich | 107.64(W)×172.224(H) mm |
| Kontur Gréisst | 122.2(W)×210.95(H) ×3.95(D) mm |
| Hellegkeet | 350 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 63% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 130g (Max.) |
| Panel Modell | TV080WUM-AK1 |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 850:1 (Typ.) (TM) |
| Display Modus | - |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | 7S3P WLED , 15K hours , Without Driver |
| Touchscreens | PCAP, Optical Bonding |
| Applikatioun | Pad & Tablet |
