| Part Number | TM070RDSG08 |
| Mark | TIANMA |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 10S3P WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | TIANMA |
| Écran Gréisst | 7.0 inch |
| Pixel Zuel | 800(RGB)×480 (WVGA) 133PPI |
| aktiv Beräich (mm) | 152.4 × 91.44 (H×V) |
| Bezel Beräich (mm) | 155.4 × 94.44 (H×V) |
| luminance | 500 cd/m² (Typ.) |
| Vue Wénkel | 70/70/70/60 (Typ.)(CR≥10) |
| gutt Vue op | - |
| Faarfdéift | 262K/16.7M 70% NTSC |
| mass | 176g (Typ.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | TM070RDSG08 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 166.4 × 107.2 × 8.5 (H×V×D) |
| Behandlung | Antiglare |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH08 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
