| Part Number | TM028HDHG30 |
| Mark | TIANMA |
| Gréisst | 2.8 |
| Applikatioun | Handheld & PDA |
| Opléisung | 240×320 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | TIANMA |
| Panel Modell | TM028HDHG30 |
| Panel Gréisst | 2.8" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 240(RGB)×320, QVGA, 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 43.2(W)×57.6(H) mm |
| bezel Ouverture | - |
| Hellegkeet | - |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Wénkel | - |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | - |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 65% NTSC |
| Lampe Typ | WLED |
| Frequenz | - |
| Touchscreens | Without |
| Panel Gewiicht | - |
| Applikatioun | Handheld & PDA |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
