| Part Number | TL055BDXP03 |
| Mark | TIANMA |
| Gréisst | 5.5 |
| Applikatioun | Mobile Phone |
| Opléisung | 1440×2560 |
| Zesummesetzung | LCM , LTPS TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 5S3P WLED |
| Interface | MIPI |
| Fabrikant beschwéiert | TIANMA |
| Écran Gréisst | 5.5 inch |
| Pixel Zuel | 1440(RGB)×2560 (Quad-HD) 537PPI |
| aktiv Beräich (mm) | 68.04 × 120.96 (H×V) |
| luminance | - |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% NTSC |
| mass | TBD |
| Erfrëschungsrate | 70Hz |
| Signal Typ | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| Spannungsversuergung | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| max. Bewäertungen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| Modell Numm | TL055BDXP03 |
| Écran Typ | LCM , LTPS TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Äntwert | 8 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | SFT, Normally Black, Transmissive |
| benotzt fir | Mobile Phone |
| touchscreen | Without |
