| Part Number | T260XW01 V3 |
| Mark | AUO |
| Gréisst | 26.0 |
| Applikatioun | LCTV |
| Opléisung | 1280×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 550 |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | T260XW01 V3 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 26.0 inch |
| Resolutioun | 1280(RGB)×768 , WXGA |
| Display Modus | VA, Normally Black, Transmissive |
| aktiv Beräich | 566.4×339.84 mm |
| skizzéieren | 620.8×389 mm |
| Uewerfläch | Antiglare, Hard coating, Antireflection |
| Hellegkeet | 550 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 15/10 (Typ.)(Tr/Td); 12 (Typ.)(G to G) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 16 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | LCTV |
