| Part Number | LQ197V1LC17 |
| Mark | SHARP |
| Gréisst | 19.7 |
| Applikatioun | LCTV |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 260 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SHARP |
| Panel Modell | LQ197V1LC17 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 19.7 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 401.28×298.8 mm |
| skizzéieren | 448.1×340.1 mm |
| Uewerfläch | Hard coating (2H) |
| Hellegkeet | 260 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | LCTV |
