AUO T315XW06 V5 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


T315XW06 V5

T315XW06 V5
T315XW06 V5
T315XW06 V5
T315XW06 V5 thumb T315XW06 V5 thumb T315XW06 V5 thumb
Mark
AUO
Gréisst
31.5
Applikatioun
LCTV
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
350
CR
3000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
12676
Spezifikatioune

Part Number T315XW06 V5
MarkAUO
Gréisst31.5
ApplikatiounLCTV
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet350
CR3000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellT315XW06 V5
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst31.5 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusAMVA, Normally Black, Transmissive
aktiv Beräich697.685×392.256 mm
skizzéieren735.4×433 mm
UewerflächAntiglare (Haze 2%), Hard coating (3H)
Hellegkeet350 cd/m² (Typ.)
Kontrast Verhältnis3000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit6.5 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
T315XW01 V9 AUO 31.5 1366×768
T315XW02 VK AUO 31.5 1366×768
T315XW02 VL AUO 31.5 1366×768
T315XW03 VD AUO 31.5 1366×768
T315XW03 VE AUO 31.5 1366×768
T315XW04 V3 AUO 31.5 1366×768
T315XW06 V3 AUO 31.5 1366×768
T315XW06 V5 AUO 31.5 1366×768
T315XW07 V0 AUO 31.5 1366×768
T315XW07 V2 AUO 31.5 1366×768
