| Part Number | QV101WUB-N80 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1920×1200 |
| Zesummesetzung | CELL , a-Si TFT-LC |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | |
| Fabrikant beschwéiert | BOE |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 1920(RGB)×1200 (WUXGA) 224PPI |
| aktiv Beräich (mm) | 216.806 × 135.504 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 0 (cd/m²) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Glas deck | - |
| Faarfdéift | 16.7M 72% NTSC |
| mass | - |
| Erfrëschungsrate | 60Hz |
| Modell Numm | QV101WUB-N80 |
| Écran Typ | CELL , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 221.81 × 145.5 (H×V×D) |
| Behandlung | Hard coating |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Aarbecht Modus | ADS, Normally Black, Transmissive |
| Äntwert | 30 (Typ.)(Tr+Td) ms |
| transmissivitéit | 3.85% (Typ.)(with Polarizer) |
| benotzt fir | Industrial |
| touchscreen | Without |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| LTN101AT03-801 | Samsung | 10.1 | 1366×768 |
| M101NWN8 R0 | IVO | 10.1 | 1366×768 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
