| Part Number | TV101WUM-NH0 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1200×1920 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | BOE |
| Panel Modell | TV101WUM-NH0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1200(RGB)×1920 , WUXGA |
| Display Modus | ADS, Normally Black, Transmissive |
| aktiv Beräich | 135.36×216.576 mm |
| skizzéieren | 143×227.93 mm |
| Uewerfläch | |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 25 (Typ.)(Tr+Tf) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S4PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 39 pins |
| Input Volt | 3.3/3.8V (Typ.)(VDD/VBAT) |
| Applikatioun | PAD |
