| Part Number | CLAA101WB03 |
| Mark | CPT |
| Gréisst | 10.1 |
| Applikatioun | NBPC |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CPT |
| Panel Modell | CLAA101WB03 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 222.726×125.222 mm |
| skizzéieren | 248.8×148×3.6 mm |
| Form Stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| CLAA104XA02CW | CPT | 10.4 | 1024×768 |
| CLAA140WA01 | CPT | 14.0 | 1280×768 |
| CLAA154WA05A | CPT | 15.4 | 1280×800 |
| CLAA156WA11A | CPT | 15.6 | 1366×768 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| CLAA170EA07Q | CPT | 17.0 | 1280×1024 |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| CLAA185WA03 | CPT | 18.5 | 1366×768 |
| B141XG09 V0 | AUO | 14.1 | 1024×768 |
| HB140WH1-504 | BOE | 14.0 | 1366×768 |
| LP133WP1-TJA1 | LG Display | 13.3 | 1440×900 |
| LP171WE2-TLA2 | LG Display | 17.1 | 1680×1050 |
| LTN141W1-L04 | Samsung | 14.1 | 1280×800 |
| LTN154AT08-001 | Samsung | 15.4 | 1280×800 |
| LTN154BT05-D01 | Samsung | 15.4 | 1440×900 |
| LTN170BT11-D01 | Samsung | 17.0 | 1440×900 |
| LTN173HT02-X01 | Samsung | 17.3 | 1920×1080 |
| N121I3-L01 | Innolux | 12.1 | 1280×800 |
