| Part Number | PM062HT1 |
| Mark | E Ink |
| Gréisst | 6.2 |
| Applikatioun | IA |
| Opléisung | 640×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | PVI |
| Panel Modell | PM062HT1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 6.2 inch |
| Resolutioun | 640(RGB)×240 , HVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 148.8×53.76 mm |
| skizzéieren | 173×70×8.9 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 15/25 (Typ.)(Tr/Td) |
| Vue Wénkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
