| Part Number | PM061WX1 |
| Mark | E Ink |
| Gréisst | 6.1 |
| Applikatioun | CNS |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | PVI |
| Panel Modell | PM061WX1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 6.1 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 136.2×72 mm |
| skizzéieren | 149×82.9 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 10/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 75/75/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 3S10PWLEDWithout Driver |
| Signal Interface | TTL (1 ch, 6-bit), 60 pins |
| Input Volt | 3.3/3.3/9.5/17.0/-8.0V (Typ.)(VCC/VDD1/VDD2/VGG/VEE) |
| rohs: | |
