| Part Number | AV094Z9M-N10 |
| Mark | BOE |
| Gréisst | 9.4 |
| Applikatioun | CNS |
| Opléisung | 1920×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 950:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | AV094Z9M-N10 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 9.4 inch |
| Resolutioun | 1920(RGB)×480 |
| Display Modus | ADS, Normally Black, Transmissive |
| aktiv Beräich | 230.4×57.6 mm |
| skizzéieren | 243.86×73.7×11.38 mm |
| Uewerfläch | Clear |
| Hellegkeet | 500 cd/m² (Min.) |
| Kontrast Verhältnis | 950:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | CNS |
