| Part Number | CLAA062LA01CW |
| Mark | CPT |
| Gréisst | 6.2 |
| Applikatioun | CNS |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 600:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | CPT |
| Panel Modell | CLAA062LA01CW |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 6.2 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 137.52×77.323 mm |
| skizzéieren | 155.2×88.2×5.3 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC), CIE193150% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 75/75/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3S6PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 60 pins |
| Input Volt | 3.3/9.2/18/-6.0/-4.0V (Typ.)(DVDD/AVDD/VDDG/VEEG/VCOM) |
| Applikatioun | CNS |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| C058GW01 V0 | AUO | 5.8 | 400×240 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| L5F30369P01 | SANYO | 6.5 | 800×480 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PW070NS1W2 | E Ink | 7.0 | 480×320 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
