| Part Number | M090SWP1 R0 |
| Mark | IVO |
| Gréisst | 9.0 |
| Applikatioun | CNS |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | IVO |
| Panel Modell | M090SWP1 R0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 9.0 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 198×111.696 mm |
| skizzéieren | 211.1×128.4×7.1 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Äntwert Zäit | 10/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | CNS |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| NL8048BC24-14NH | NLT | 9.0 | 800×480 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
| TX31D16VM2BAA | KOE | 12.2 | 1024×310 |
