| Part Number | UG-9664HDDAG01 |
| Mark | WiseChip |
| Gréisst | 0.95 |
| Applikatioun | IA |
| Opléisung | 96×64 |
| Zesummesetzung | OLED |
| Hellegkeet | 100 |
| CR | 1000:1 |
| Faarwen | 65K |
| Géigeliicht | self |
| Interface | CPU/SPI |
| Panel Mark | WiseChip |
| Panel Modell | UG-9664HDDAG01 |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 0.95 inch |
| Resolutioun | 96(RGB)×64 |
| aktiv Beräich | 20.14×13.42 mm |
| skizzéieren | 25.7×22.2×1.6 mm |
| Uewerfläch | |
| Hellegkeet | 100 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) |
| weisen Faarwen | 65K |
| Vue Wénkel | 80/80/80/80 (Min.)(L/R/U/D) |
| Chauffeur ic | COG Built-in SSD1331Z |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, 23 pins |
| Input Volt | 2.8/2.8/14.0V (Typ.)(VDD/VDDIO/VCC) |
| rohs: | |
| Applikatioun | IA |
