| Part Number | AC121SA01 |
| Mark | Mitsubishi |
| Gréisst | 12.1 |
| Applikatioun | IA |
| Opléisung | 800×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 800:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | Mitsubishi |
| Panel Modell | AC121SA01 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.1 inch |
| Resolutioun | 800(RGB)×600 , SVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 246×184.5 mm |
| skizzéieren | 260×203×10 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 4/12 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH11-DE1 | Mitsubishi | 12.1 | 1280×800 |
| AC121SA01 | Mitsubishi | 12.1 | 800×600 |
| AC121SA02 | Mitsubishi | 12.1 | 800×600 |
| G121X1-L04 | Innolux | 12.1 | 1024×768 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LT121SU-121 | Samsung | 12.1 | 800×600 |
| LTN121W1-L03 | Samsung | 12.1 | 1280×800 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| G190EAN01.0 | AUO | 19.0 | 1280×1024 |
| LM10V332 | SHARP | 10.4 | 640×480 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| TX14D11VM1CAA | KOE | 5.7 | 320×240 |
