| Part Number | N156DCE-GA1 |
| Mark | Innolux |
| Gréisst | 15.6 |
| Applikatioun | Laptop |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | Innolux |
| Panel Modell | N156DCE-GA1 (CMN15E1) |
| Panel Gréisst | 15.6" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 3840(RGB)×2160, UHD, 283PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 344.218(W)×193.622(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 367.98(W)×218.8(H) ×3.2(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AAS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 16/14 (Typ.)(Tr/Td) |
| weisen Faarwen | 16.7M 72% NTSC |
| Lampe Typ | WLED , 15K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Applikatioun | Laptop |
| Signal Interface | eDP (4 Lanes) , eDP1.2 , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LP156WD1-TLA2 | LG Display | 15.6 | 1600×900 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP156WH3-TLA1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLC1 | LG Display | 15.6 | 1366×768 |
| LQ156D1JX03 | SHARP | 15.6 | 3840×2160 |
| LTN156AT24-P01 | Samsung | 15.6 | 1366×768 |
| LTN156HT01-101 | Samsung | 15.6 | 1920×1080 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| N156HGE-EAL Rev.C1 | Innolux | 15.6 | 1920×1080 |
