N156B6-L0A

N156B6-L0A
N156B6-L0A
N156B6-L0A
N156B6-L0A thumb N156B6-L0A thumb N156B6-L0A thumb
Mark
Innolux
Gréisst
15.6
Applikatioun
NBPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
220
CR
500:1
Faarwen
262K
Backlight
WLED
Interface
LVDS
In Stock
11141
Spezifikatioune

Part Number N156B6-L0A
MarkInnolux
Gréisst15.6
ApplikatiounNBPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet220
CR500:1
Faarwen262K
GéigeliichtWLED
InterfaceLVDS
Panel MarkCMO
Panel ModellN156B6-L0A 61 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst15.6 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich344.232×193.536 mm
skizzéieren359.3×209.5×5.5 mm
Form StilWedge (PCBA Bent, Depth ≥5.2mm)
UewerflächAntiglare, Hard coating (3H)
Hellegkeet220 cd/m² (Typ.)
Kontrast Verhältnis500:1 (Typ.)
weisen Faarwen262K (6-bit), CIE193160%
Äntwert Zäit3/8 (Typ.)(Tr/Td)
Vue Wénkel45/45/20/45 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 6-bit), 40 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
Famill Modell
N156B3-L01 Innolux 15.6 1366×768
N156B3-L0A Innolux 15.6 1366×768
N156B6-L01 Innolux 15.6 1366×768
N156B6-L06 Innolux 15.6 1366×768
N156B6-L0A Innolux 15.6 1366×768
N156BGE-E11 Innolux 15.6 1366×768
N156BGE-E21 Innolux 15.6 1366×768
N156BGE-E42 Innolux 15.6 1366×768
N156BGE-EA1 Innolux 15.6 1366×768
N156BGE-L31 Innolux 15.6 1366×768
