| Part Number | M200O3-LA3 |
| Mark | Innolux |
| Gréisst | 20.0 |
| Applikatioun | DMPC |
| Opléisung | 1600×900 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | M200O3-LA3 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 20.0 inch |
| Resolutioun | 1600(RGB)×900 , HD+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 442.8×249.075 mm |
| skizzéieren | 462.8×272×11 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 1.5/3.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 11S4PWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM215WF2-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM300WQ5-SDA1 | LG Display | 30.0 | 2560×1600 |
| LQ150X1DG10 | SHARP | 15.0 | 1024×768 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| M215HJJ-L30 Rev.C1 | Innolux | 21.5 | 1920×1080 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| NA19020-C961 | Fujitsu | 19.0 | 1280×1024 |
