| Part Number | M101GWWF R0 |
| Mark | IVO |
| Gréisst | 10.1 |
| Applikatioun | Laptop |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | IVO |
| Modell | M101GWWF R0 |
| diagonal Gréisst | 10.1 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×800 [WXGA] 149PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 216.96(H)×135.6(V) mm |
| kontur dim. | 229.46(H)×149.1(V) ×4.56(D) mm |
| bezel Beräich | - |
| Behandlung | Glare (Haze 0%), Hard coating (3H) |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M |
| Liichtquell | WLED , 25K hours , With LED Driver |
| Form Stil | Slim (PCBA Bent, T≤3.0mm) |
| entworf fir | Laptop |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| B101AW06 V4 | AUO | 10.1 | 1024×600 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
