| Part Number | HV101WU1-1E3 |
| Mark | HYDIS |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 700 |
| CR | 750:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS/MIPI |
| Panel Mark | HYDIS |
| Panel Modell | HV101WU1-1E3 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | AFFS, Normally Black, Transmissive |
| aktiv Beräich | 216.576×135.36 mm |
| skizzéieren | 229×153×4.8 mm |
| Uewerfläch | |
| Hellegkeet | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 750:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS/MIPI, 45 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
