| Part Number | M090AWP4 R1 |
| Mark | IVO |
| Gréisst | 9.0 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 800×480 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K |
| Géigeliicht | WLED , No Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | IVO |
| Écran Gréisst | 9.0 inch |
| Pixel Zuel | 800(RGB)×480 (WVGA) 104PPI |
| aktiv Beräich (mm) | 198 × 112.08 (H×V) |
| Bezel Beräich (mm) | 200.2 × 114.28 (H×V) |
| luminance | 750 cd/m² (Typ.) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| gutt Vue op | 6 o'clock |
| Faarfdéift | 262K 70% NTSC |
| mass | - |
| Erfrëschungsrate | 60Hz |
| Signal Typ | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| max. Bewäertungen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| Modell Numm | M090AWP4 R1 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 700 : 1 (Typ.) (TM) |
| Äntwert | 12 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Outdoor High Brightness Automotive Display |
| touchscreen | Without |
