| Part Number | LTM07C383 |
| Mark | TOSHIBA |
| Gréisst | 7.8 |
| Applikatioun | |
| Opléisung | 480×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 250:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | TOSHIBA |
| Panel Modell | LTM07C383 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 7.8 inch |
| Resolutioun | 480(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 172.1×96.6 mm |
| skizzéieren | 188×120 mm |
| Uewerfläch | |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 250:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 50/50 (Max.)(Tr/Td) |
| Vue Wénkel | |
| Lampe Typ | 1 pcsCCFLEmbedded (Inverter) |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.)(Vpp) |
