| Part Number | LTM035A776C |
| Mark | TOSHIBA |
| Gréisst | 3.5 |
| Applikatioun | HHP |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | 40 |
| CR | |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | Toshiba Matsushita |
| Panel Modell | LTM035A776C |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Reflective |
| aktiv Beräich | 53.64×71.52 mm |
| skizzéieren | 70×92.2×5.35 mm |
| Uewerfläch | |
| Hellegkeet | 40 cd/m² (Typ.) |
| Kontrast Verhältnis | 15:1 (Typ.)(Reflective) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 50/50 (Max.)(Tr/Td) |
| Vue Wénkel | |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 50 pins |
| Input Volt | 3.3/5.0/15.0/-12.0/(VGL+3.3)V (Typ.)(DVDD/AVDD/VGH/VGL/GVDD) |
| Applikatioun | HHP |
