| Part Number | LS027T3DG01 |
| Mark | SHARP |
| Gréisst | 2.7 |
| Applikatioun | DSC |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 300:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Serial RGB |
| Panel Mark | SHARP |
| Panel Modell | LS027T3DG01 |
| Panel Typ | CG-Silicon , LCM |
| Panel Gréisst | 2.7 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 59.49×33.48 mm |
| skizzéieren | 65×45 mm |
| Uewerfläch | Antiglare, Hard coating (2H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30/50 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | Serial RGB (8-bit) + SPI, 45 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | DSC |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| A027DN03 V1 | AUO | 2.7 | 320×240 |
| A030DW01 V0 | AUO | 3.0 | 320×240 |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| DLC0350FVG-5 | Other | 3.5 | 320×240 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| LTV250QV-F03 | Samsung | 2.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
