| Part Number | LQ070Y3DG02 |
| Mark | SHARP |
| Gréisst | 7.0 |
| Applikatioun | DPF |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 450:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ070Y3DG02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800×480(RGB) , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 152.4×91.44 mm |
| skizzéieren | 164.9×104×5.3 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 450:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193148% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S3PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 51 pins |
| Input Volt | 1.8/2.85V (Typ.)(VDDIO/VCI) |
| Applikatioun | DPF |
