| Part Number | LPM011M133B |
| Mark | JDI |
| Gréisst | 1.1 |
| Applikatioun | Wearable Round Displ |
| Opléisung | 218×218 |
| Zesummesetzung | LTPS TFT-LCD, CELL |
| Hellegkeet | |
| CR | 20:1 |
| Faarwen | 64 |
| Géigeliicht | No |
| Interface | |
| Mark | JDI |
| Modell | LPM011M133B |
| diagonal Gréisst | 1.1 inch |
| Typ | LTPS TFT-LCD, CELL |
| Pixel Format | 218(RGB)×218 200PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 27.6642(H)×27.6642(V) mm |
| kontur dim. | 30.465(H)×31.865(V) ×0.884(D) mm |
| bezel Beräich | - |
| Behandlung | Hard coating (2H) |
| luminance | - |
| Kontrast Verhältnis | 20:1 (Typ.) (RF) |
| Vue Richtung | - |
| Äntwert Zäit | 3/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/65/65/60 (Typ.)(CR≥2) |
| Betribssystemer Modus | ECB, Normally Black, Reflective |
| Plackedicke | - |
| Iwwerdroung | 0.3% (Typ.) |
| Ënnerstëtzung Faarf | 64 23% NTSC |
| Liichtquell | No B/L |
| Gewiicht | 1.50g (Typ.) |
| entworf fir | Wearable Round Display |
| Frame Taux | 30Hz |
| Touch Panel | Without |
| Stroumversuergung | 3.2/4.5V (Typ.)(VDD1/VDD2) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| LPM010R030B | JDI | 0.99 | 180×180 |
| LPM012A154A | JDI | 1.2 | 218×218 |
| LPM013M091A | JDI | 1.34 | 320×300 |
| OEL9M0082-Y-E | Other | 1.1 | 128×128 |
| OEL9M1007-G-E | Other | 1.1 | 96×96 |
| OEL9M1007-R-E | Other | 1.1 | 96×96 |
| OEL9M1007-W-E | Other | 1.1 | 96×96 |
| RGC11096096FR007 | RiTdisplay | 1.1 | 96×96 |
| RGS11128036WR014 | RiTdisplay | 1.1 | 128×36 |
| UG-9696TDDCG02 | WiseChip | 1.1 | 96×96 |
