| Part Number | LPM010R030B |
| Mark | JDI |
| Gréisst | 0.99 |
| Applikatioun | SW |
| Opléisung | 180×180 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | |
| Faarwen | 8 |
| Géigeliicht | No B/L |
| Interface | |
| Panel Mark | JDI |
| Panel Modell | LPM010R030B |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 0.99 inch |
| Resolutioun | 180(RGB)×180 |
| Display Modus | ECB, Normally Black, Reflective |
| aktiv Beräich | 25.11×25.11 mm |
| skizzéieren | 29.51×31.11×1.156 mm |
| Uewerfläch | Hard coating (2H) |
| Hellegkeet | |
| Kontrast Verhältnis | 20:1 (Typ.)(Reflective) |
| weisen Faarwen | 8 (1-bit), CIE193123% |
| Äntwert Zäit | 3/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/65/65/60 (Typ.)(CR≥2)(L/R/U/D) |
| Frequenz | 30Hz |
| Lampe Typ | No B/L |
| Input Volt | 3.2/4.5/6.6V (Typ.)(VLCD/VDDP/VDDC) |
| Applikatioun | SW |
| LPM010R030B | JDI | 0.99 | 180×180 |
| LPM012A154A | JDI | 1.2 | 218×218 |
| LPM013M091A | JDI | 1.34 | 320×300 |
| LS010B7DH01 | SHARP | 0.99 | 128×128 |
| H139BLN01.0 | AUO | 1.39 | 400×400 |
| LS013B7DH06 | SHARP | 1.33 | 128×128 |
| OEL9M0084-B-E | Other | 0.91 | 128×32 |
| OEL9M0084-W-E | Other | 0.91 | 128×32 |
| OEL9M0084-Y-E | Other | 0.91 | 128×32 |
| OEL9M1004-L4-E | Other | 1.5 | 128×128 |
| OEL9M1007-R-E | Other | 1.1 | 96×96 |
| OEL9M1010-R-E | Other | 0.95 | 96×64 |
| OEL9M1010-W-E | Other | 0.95 | 96×64 |
| RGS18160128FH003 | RiTdisplay | 1.8 | 160×128 |
