| Part Number | HJ070IA-01I |
| Mark | Innolux |
| Gréisst | 7.0 |
| Applikatioun | PAD |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | HJ070IA-01I |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 1024(RGB)×600 , WSVGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 153.6×90 mm |
| skizzéieren | 164.1×102.6×4.59 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4S5PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 31 pins |
| Input Volt | 3.7V (Typ.) |
| Applikatioun | PAD |
| AT070TN84 | Innolux | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| HJ070IA-01I | Innolux | 7.0 | 1024×600 |
| HJ070IA-02F | Innolux | 7.0 | 1280×800 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HJ070NA-01U | Innolux | 7.0 | 1024×600 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HJ070NA-13D | Innolux | 7.0 | 1024×600 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LTA070B240F | TOSHIBA | 7.0 | 480×234 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00-C11 | HannStar | 10.1 | 1280×800 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LTN070NL01 | Samsung | 7.0 | 1024×600 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
