| Part Number | GV101WXB-NN0-3GP0 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | GV101WXB-NN0-3GP0 |
| Panel Gréisst | 10.1" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 1280(RGB)×800, WXGA, 149PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 216.96(W)×135.6(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 221.96(W)×144.43(H) ×1.06(D) mm |
| Uewerfläch | Without Polarizer, Hard coating |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 50% NTSC |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COG Built-in 2 source chips |
| Panel Gewiicht | - |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
