AUO B101EAN01.4 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


B101EAN01.4

B101EAN01.4
B101EAN01.4
B101EAN01.4
B101EAN01.4 thumb B101EAN01.4 thumb B101EAN01.4 thumb
Mark
AUO
Gréisst
10.1
Applikatioun
PAD
Opléisung
1280×800
Zesummesetzung
LCM
Hellegkeet
350
CR
800:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
8114
Spezifikatioune

Part Number B101EAN01.4
MarkAUO
Gréisst10.1
ApplikatiounPAD
Opléisung1280×800
ZesummesetzungLCM
Hellegkeet350
CR800:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellB101EAN01.4
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst10.1 inch
Resolutioun1280(RGB)×800 , WXGA
Display ModusAHVA, Normally Black, Transmissive
aktiv Beräich216.96×135.6 mm
skizzéieren227.9×147.8×4.6 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet350 cd/m² (Typ.)
Kontrast Verhältnis800:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193150%
Äntwert Zäit30 (Typ.)(Tr+Td)
Vue Wénkel85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ6S5PWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 8-bit), 40 pins
Input Volt3.3V (Typ.)
ApplikatiounPAD
Famill Modell
B101EAN01.1 AUO 10.1 1280×800
B101EAN01.2 AUO 10.1 1280×800
B101EAN01.5 AUO 10.1 1280×800
B101EAN01.6 AUO 10.1 1280×800
B101EAN01.7 AUO 10.1 1280×800
B101EAN02.2 AUO 10.1 800×1280
B101EW01 V1 AUO 10.1 1280×720
B101EW02 V0 AUO 10.1 1280×720
B101EW02 V1 AUO 10.1 1280×720
B101EW05 V1 AUO 10.1 1280×800
