| Part Number | G230HAN01.1 |
| Mark | AUO |
| Gréisst | 23.0 |
| Applikatioun | GM |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G230HAN01.1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 23.0 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | AHVA, Normally Black, Transmissive |
| aktiv Beräich | 509.184×286.416 mm |
| skizzéieren | 533.2×312×11 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 8/8 (Typ.)(Tr/Td); 14 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 18S4PWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | GM |
| G230HAN01.1 | AUO | 23.0 | 1920×1080 |
| LM230WF1-TLA3 | LG Display | 23.0 | 1920×1080 |
| LM230WF2-SLA2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLL1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LTM230HT05 | Samsung | 23.0 | 1920×1080 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| LTM230TT01 | Samsung | 23.0 | 2048×1152 |
| T230XW01 V1 | AUO | 23.0 | 1366×768 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| G154I1-LE1 | Innolux | 15.4 | 1280×800 |
| G220SVN01.0 | AUO | 22.0 | 1680×1050 |
| G230HAN01.1 | AUO | 23.0 | 1920×1080 |
| LQ061Y1VG01 | SHARP | 6.1 | 800×480 |
| LQ121S1LG51 | SHARP | 12.1 | 800×600 |
| LQ150X1LG96 | SHARP | 15.0 | 1024×768 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LQ190E1LW62 | SHARP | 19.0 | 1280×1024 |
| LTA159B870F | TOSHIBA | 15.9 | 1280×645 |
