| Part Number | LM230WF5-TLC1 |
| Mark | LG Display |
| Gréisst | 23.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LM230WF5-TLC1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 23.0 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 509.184×286.416 mm |
| skizzéieren | 533.2×312×11.8 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193168% |
| Äntwert Zäit | 1.3/3.7 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3 stringsWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| LM230WF1-TLA3 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLK1 | LG Display | 23.0 | 1920×1080 |
| LM230WF4-TLA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF4 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLG1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| LM230WF8-TLA2 | LG Display | 23.0 | 1920×1080 |
| CLAA170ES01E | CPT | 17.0 | 1280×1024 |
| HR215WU1-100 | BOE | 21.5 | 1920×1080 |
| ITSX98E | IDTech | 18.1 | 1280×1024 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| NL160120BC27-09 | NLT | 21.3 | 1600×1200 |
| QD17EL07 Rev.09 | QDI | 17.0 | 1280×1024 |
