| Part Number | G170J1-LE1 |
| Mark | Innolux |
| Gréisst | 17.0 |
| Applikatioun | IA |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 600 |
| CR | 2000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | INNOLUX |
| Panel Modell | G170J1-LE1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 17.0 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | Super MVA, Normally Black, Transmissive |
| aktiv Beräich | 365.76×228.6 mm |
| skizzéieren | 386.8×250.8×19 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 20/9 (Typ.)(Tr/Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | IA |
