| Part Number | G101EAN02.2 |
| Mark | AUO |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G101EAN02.2 |
| Panel Gréisst | 10.1" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1280(RGB)×800, WXGA, 149PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 216.96(W)×135.6(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 227.91(W)×148(H) ×7.75(D) mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AHVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 29 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 50% NTSC |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 290g (Max.) |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
