| Part Number | CT035TN02 |
| Mark | Innolux |
| Gréisst | 3.5 |
| Applikatioun | MPH |
| Opléisung | 320×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 320 |
| CR | 500:1 |
| Faarwen | 65K/262K |
| Géigeliicht | WLED |
| Interface | CPU/RGB/SPI |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | CT035TN02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 320(RGB)×480 , HVGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 48.96×73.44 mm |
| skizzéieren | 54.76×85.24×2.1 mm |
| Uewerfläch | |
| Hellegkeet | 320 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 65K/262K , CIE193170% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1S5PWLEDWithout Driver |
| Signal Interface | CPU/RGB/SPI, 50 pins |
| Input Volt | 2.8/2.8V (Typ.)(VDD3/VCI) |
| Applikatioun | MPH |
