| Part Number | CLAA100XA22XV |
| Mark | CPT |
| Gréisst | 10.0 |
| Applikatioun | PAD |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CPT |
| Panel Modell | CLAA100XA22XV |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | HFFS, Normally Black, Transmissive |
| aktiv Beräich | 202.752×152.064 mm |
| Uewerfläch | |
| Hellegkeet | |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6/8-bit), 40 pins |
| Input Volt | 3.3/13/18/-6V (Typ.)(VDD/AVDD/VGH/VGL) |
| Applikatioun | PAD |
| CLAA100XA22XV | CPT | 10.0 | 1024×768 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WA01 | CPT | 10.1 | 1366×768 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA102NA0DCW | CPT | 10.2 | 1024×600 |
| CLAA102NA1BCN | CPT | 10.2 | 1024×600 |
| CLAA102NC01CW | CPT | 10.2 | 1024×600 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| EJ101IA-01G | Innolux | 10.1 | 1280×800 |
| HE070IA-04R | Innolux | 7.0 | 800×1280 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LTL070AL03 | Samsung | 7.0 | 800×1280 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
