| Part Number | CLAA080WK0A XN |
| Mark | CPT |
| Gréisst | 8.0 |
| Applikatioun | Automotive Display |
| Opléisung | 1280×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | CPT |
| Modell | CLAA080WK0A XN |
| diagonal Gréisst | 8.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×720 [WXGA] 183PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 177.024(H)×99.576(V) mm |
| kontur dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| bezel Beräich | 179.024(H)×101.576(V) mm |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | HFFS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Liichtquell | WLED [9S3P] , 50K hours , W/O Driver |
| Gewiicht | 120/230g (Typ./Max.) |
| entworf fir | Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
