| Part Number | CLAA080WK02 XN |
| Mark | CPT |
| Gréisst | 8.0 |
| Applikatioun | Automotive Display |
| Opléisung | 1280×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | CPT |
| Modell | CLAA080WK02 XN |
| diagonal Gréisst | 8.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×720 [WXGA] 183PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 177.024(H)×99.576(V) mm |
| kontur dim. | 186.5(H)×117.22(V) ×13.1(D) mm |
| bezel Beräich | 179.03(H)×101.58(V) mm |
| Behandlung | Antiglare (Haze 25%) |
| luminance | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | HFFS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M 70% NTSC |
| Liichtquell | WLED [5S4P] , 30K hours , W/O Driver |
| Gewiicht | TBD |
| entworf fir | Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| Stroumversuergung | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Ëmwelt | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
