| Part Number | C050FTN01.0 |
| Mark | AUO |
| Gréisst | 5.0 |
| Applikatioun | CNS |
| Opléisung | 480×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 1100 |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | AUO |
| Panel Modell | C050FTN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.0 inch |
| Resolutioun | 480(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 110.88×62.478 mm |
| skizzéieren | 124×75.36×8.25 mm |
| Uewerfläch | |
| Hellegkeet | 1100 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193165% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S2PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | CNS |
