| Part Number | B154SW01 V2 |
| Mark | AUO |
| Gréisst | 15.4 |
| Applikatioun | NBPC |
| Opléisung | 1680×1050 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | B154SW01 V2 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.4 inch |
| Resolutioun | 1680(RGB)×1050 , WSXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 331.38×207.11 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 60/60/45/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFL |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Applikatioun | NBPC |
| B154SW01 V0 | AUO | 15.4 | 1680×1050 |
| B154SW01 V1 | AUO | 15.4 | 1680×1050 |
| B154SW01 V2 | AUO | 15.4 | 1680×1050 |
| B154SW01 V9 | AUO | 15.4 | 1680×1050 |
| B154SW01 VB | AUO | 15.4 | 1680×1050 |
| B154SW02 V0 | AUO | 15.4 | 1680×1050 |
| B154SW02 V3 | AUO | 15.4 | 1680×1050 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LQ154M1LW02 | SHARP | 15.4 | 1920×1200 |
| QD15TL04 Rev.05 | QDI | 15.4 | 1280×800 |
| B156HW01 V3 | AUO | 15.6 | 1920×1080 |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| LP156WH4-TPA1 | LG Display | 15.6 | 1366×768 |
| LP201WE1-TLA1 | LG Display | 20.1 | 1680×1050 |
| LTN140AT20-301 | Samsung | 14.0 | 1366×768 |
| LTN170BT11-D03 | Samsung | 17.0 | 1440×900 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
| N121IB-L06 | Innolux | 12.1 | 1280×800 |
| N144NGE-E41 | Innolux | 14.4 | 1792×768 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
