| Part Number | B154SW01 VB |
| Mark | AUO |
| Gréisst | 15.4 |
| Applikatioun | NBPC |
| Opléisung | 1680×1050 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | B154SW01 VB 7 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.4 inch |
| Resolutioun | 1680(RGB)×1050 , WSXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 331.38×207.11 mm |
| skizzéieren | 344×222×6.5 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B154SW01 V0 | AUO | 15.4 | 1680×1050 |
| B154SW01 V1 | AUO | 15.4 | 1680×1050 |
| B154SW01 V2 | AUO | 15.4 | 1680×1050 |
| B154SW01 V9 | AUO | 15.4 | 1680×1050 |
| B154SW01 VB | AUO | 15.4 | 1680×1050 |
| B154SW02 V0 | AUO | 15.4 | 1680×1050 |
| B154SW02 V3 | AUO | 15.4 | 1680×1050 |
| LTN154U1-L01 | Samsung | 15.4 | 1920×1200 |
| LTN154U1-L03 | Samsung | 15.4 | 1920×1200 |
| B133XW01 V0 | AUO | 13.3 | 1366×768 |
| B140RTN01.0 | AUO | 14.0 | 1600×900 |
| B154PW04 V6 | AUO | 15.4 | 1440×900 |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP141WP2-TLB1 | LG Display | 14.1 | 1440×900 |
| LP154WX5-TLC1 | LG Display | 15.4 | 1280×800 |
| LTD111EWAS | TOSHIBA | 11.1 | 1366×768 |
| LTN156AT02-D04 | Samsung | 15.6 | 1366×768 |
| LTN156AT29-L01 | Samsung | 15.6 | 1366×768 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
