AUO B156HW01 V3 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


B156HW01 V3

B156HW01 V3
B156HW01 V3
B156HW01 V3 thumb B156HW01 V3 thumb
Mark
AUO
Gréisst
15.6
Applikatioun
NBPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
220
CR
400:1
Faarwen
262K
Backlight
WLED
Interface
LVDS
In Stock
9125
Spezifikatioune

Part Number B156HW01 V3
MarkAUO
Gréisst15.6
ApplikatiounNBPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet220
CR400:1
Faarwen262K
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellB156HW01 V3 20 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst15.6 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich344.16×193.59 mm
skizzéieren359.3×209.5×5.7 mm
Form StilWedge (PCBA Bent, Depth ≥5.2mm)
UewerflächAntiglare
Hellegkeet220 cd/m² (Typ.)
Kontrast Verhältnis400:1 (Typ.)
weisen Faarwen262K (6-bit), CIE193160%
Äntwert Zäit2/6 (Typ.)(Tr/Td)
Vue Wénkel70/70/60/60 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (2 ch, 6-bit), 40 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
Famill Modell
B156HAK01.0 AUO 15.6 1920×1080
B156HAN01.2 AUO 15.6 1920×1080
B156HAT01.0 AUO 15.6 1920×1080
B156HB01 V0 AUO 15.6 1920×1080
B156HTN01.1 AUO 15.6 1920×1080
B156HTN03.3 AUO 15.6 1920×1080
B156HW01 V1 AUO 15.6 1920×1080
B156HW01 V3 AUO 15.6 1920×1080
B156HW02 V1 AUO 15.6 1920×1080
B156HW03 V0 AUO 15.6 1920×1080
