| Part Number | B140QAN02.2 |
| Mark | AUO |
| Gréisst | 14.0 |
| Applikatioun | Laptop |
| Opléisung | 2560×1440 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | AUO |
| Panel Modell | B140QAN02.2 |
| Panel Gréisst | 14.0" |
| Panel Typ | LTPS TFT-LCD, LCM |
| Resolutioun | 2560(RGB)×1440, Quad-HD, 210PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 309.35(W)×174.01(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 315.05(W)×195.6(H) ×2.4(D) mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | - |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | AHVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M |
| Lampe Typ | WLED , 15K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Applikatioun | Laptop |
| Signal Interface | eDP (4 Lanes) Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
