| Part Number | B140QAN01.0 |
| Mark | AUO |
| Gréisst | 14.0 |
| Applikatioun | NBPC |
| Opléisung | 2560×1440 |
| Zesummesetzung | LCM |
| Hellegkeet | 340 |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | AUO |
| Panel Modell | B140QAN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 14.0 inch |
| Resolutioun | 2560(RGB)×1440 , Quad-HD |
| Display Modus | AHVA, Normally Black, Transmissive |
| aktiv Beräich | 309.35×174.01 mm |
| skizzéieren | 320.4×205.1×2.6 mm |
| Form Stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 340 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| B140HAN01.8 | AUO | 14.0 | 1920×1080 |
| B140QAN01.0 | AUO | 14.0 | 2560×1440 |
| B140QAN01.1 | AUO | 14.0 | 2560×1440 |
| B140RW01 V2 | AUO | 14.0 | 1600×900 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP140WD2-TLD2 | LG Display | 14.0 | 1600×900 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LQ140Z1JW01 | SHARP | 14.0 | 3200×1800 |
| LTN140AT07-W01 | Samsung | 14.0 | 1366×768 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| B133EW01 V0 | AUO | 13.3 | 1280×800 |
| LP133X5-A2IB | LG Display | 13.3 | 1024×768 |
| LQ164M1LG4B | SHARP | 16.4 | 1920×1080 |
| LTM10C306Y | TOSHIBA | 10.4 | 1024×768 |
| LTN121AT06-G01 | Samsung | 12.1 | 1280×800 |
| LTN154U1-L03 | Samsung | 15.4 | 1920×1200 |
| LTN156AT05-701 | Samsung | 15.6 | 1366×768 |
| LTN173KT02-W01 | Samsung | 17.3 | 1600×900 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
