| Part Number | AM-800600MTMQW-50H |
| Mark | AMPIRE |
| Gréisst | 8.4 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 800×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 6S5P |
| Interface | |
| Panel Mark | AMPIRE |
| Panel Gréisst | 8.4" |
| Resolutioun | 800(RGB)×600, SVGA, 119PPI |
| Affichage Beräich | 170.4(W)×127.8(H) mm |
| Kontur Gréisst | 189.75(W)×149.4(H) ×5.3(D) mm |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Vue Wénkel | 75/75/60/70 (Typ.)(CR≥10) |
| beschte Vue op | - |
| weisen Faarwen | 262K/16.7M |
| Frequenz | 60Hz |
| Gewiicht | TBD |
| Panel Modell | AM-800600MTMQW-50H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 173.4(W)×130.8(H) mm |
| Uewerfläch | - |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| Lampe Typ | 6S5P WLED , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial Outdoor High Brightness |
