| Part Number | AM-1024600K7TMQW-T04H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K |
| Géigeliicht | 8S3P |
| Interface | |
| Panel Mark | AMPIRE |
| Panel Gréisst | 7.0" |
| Resolutioun | 1024(RGB)×600, WSVGA, 169PPI |
| Affichage Beräich | 153.6(W)×90(H) mm |
| Kontur Gréisst | 165.5(W)×104.44(H) ×10.81(D) mm |
| Hellegkeet | 850 cd/m² (Typ.) |
| Vue Wénkel | 75/75/70/75 (Typ.)(CR≥10) |
| beschte Vue op | 6 o'clock |
| weisen Faarwen | 262K |
| Frequenz | 60Hz |
| Gewiicht | TBD |
| Panel Modell | AM-1024600K7TMQW-T04H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 20/20 (Typ.)(Tr/Td) |
| Lampe Typ | 8S3P WLED , 50K hours , With LED Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
