| Part Number | AM-1024600K5TMQW-01H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S3P WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AMPIRE |
| Écran Gréisst | 7.0 inch |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 169PPI |
| aktiv Beräich (mm) | 153.6 × 90 (H×V) |
| Bezel Beräich (mm) | 156.2 × 92.6 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| Vue Wénkel | 75/75/70/75 (Typ.)(CR≥10) |
| gutt Vue op | - |
| Faarfdéift | 16.7M |
| mass | TBD |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | AM-1024600K5TMQW-01H |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 165.5 × 104.44 × 9.46 (H×V×D) |
| Behandlung | Glare (Haze 0%), Hard coating |
| Kontrast Verhältnis | 700 : 1 (Typ.) (TM) |
| Äntwert | 20/20 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial Outdoor High Brightness |
| touchscreen | Without |
